354 Rockwell Automation Publication 1426-UM001F-EN-P - November 2013
Appendix A PowerMonitor 5000 Unit Data Tables
29 Real V3_IEC_THD_% V3-N IEC Total Harmonic Distortion % 0.00…100.00
30 Real VN_G_IEC_THD_% VGN-N IEC Total Harmonic Distortion % 0.00…100.00
31 Real Avg_IEC_THD_V_% Average V1/V2/V3 to N IEC Total Harmonic Distortion % 0.00…100.00
32 Real V1_V2_IEC_THD_% V1-V2 IEC Total Harmonic Distortion % 0.00…100.00
33 Real V2_V3_IEC_THD_% V2-V3 IEC Total Harmonic Distortion % 0.00…100.00
34 Real V3_V1_IEC_THD_% V3-V1 IEC Total Harmonic Distortion % 0.00…100.00
35 Real Avg_IEC_THD_V_V_% Average IEC THD for V1-V2, V2-V3, V3-V1 % 0.00…100.00
36 Real I1_IEC_THD_% I1 IEC Harmonic Distortion % 0.00…100.00
37 Real I2_IEC_THD_% I2 IEC Harmonic Distortion % 0.00…100.00
38 Real I3_IEC_THD_% I3 IEC Harmonic Distortion % 0.00…100.00
39 Real I4_IEC_THD_% I4 IEC Harmonic Distortion % 0.00…100.00
40 Real Avg_IEC_THD_I_% Average I1/I2/I3 IEC Total Harmonic Distortion % 0.00…100.00
41 Real Pos_Seq_Volts Positive Sequence Voltage V 0…9.999E15
42 Real Neg_Seq_Volts Negative Sequence Voltage V 0…9.999E15
43 Real Zero_Seq_Volts Zero Sequence Voltage V 0…9.999E15
44 Real Pos_Seq_Amps Positive Sequence Amps A 0…9.999E15
45 Real Neg_Seq_Amps Negative Sequence Amps A 0…9.999E15
46 Real Zero_Seq_Amps Zero Sequence Amps A 0…9.999E15
47 Real Voltage_Unbalance_% Voltage percent unbalance % 0.00…100.00
48 Real Current_Unbalance_% Current percent unbalance % 0.00…100.00
49 Real I1_K_Factor I1 K-factor 1.00…
25,000.00
50 Real I2_K_Factor I2 K-factor 1.00…
25,000.00
51 Real I3_K_Factor I3 K-factor 1.00…
25,000.00
52…55 Real Resvd Reserved
Table 178 - PowerQuality.RealTime_PowerQuality Data Table
Element
Number Type Tag Name Description Units Range
