258 Rockwell Automation Publication 1426-UM001F-EN-P - November 2013
Appendix A PowerMonitor 5000 Unit Data Tables
13 Real Hysteresis 7 The value in magnitude or percent of reference at which the output action is deasserted.
Example: A less than condition deasserts at (threshold + hysteresis), a greater than condition
deasserts at (threshold - hysteresis). 0 0…10,000,000
14 Real Assert Delay
Seconds 7 The amount of time to delay the output action after a setpoint trigger occurs. Minimum equals
realtime update rate setting. 0 0.000…3600
15 Real Deassert Delay
Seconds 7 The amount of time to delay deassertion after the setpoint trigger releases. Minimum equals
realtime update rate setting. 0 0.000…3600
16 Real Parameter
Selection 8 Selection of the input parameter from the Setpoint Parameter Selection List . 0 0…105
17 Real Input Reference
Selection 8 Selects the type of input conditioning for non boolean parameters.
0 = Absolute Value 0 0
18 Real Test Condition 8 0 = Disabled
1 = Less Than
2 = Greater Than
3 = Equals 0 0…3
19 Real Evaluation Type 8 0 = Magnitude
1 = State
2 = Percent of Reference (not supported in the M5 model)
3 = Percent of Sliding Reference (not supported in the M5 model) 0 0…3
20 Real Threshold 8 The value, percent, or state that triggers the output action. 0 -10,000,000…
10,000,000
21 Real Hysteresis 8 The value in magnitude or percent of reference at which the output action is deasserted.
Example: A less than condition deasserts at (threshold + hysteresis), a greater than condition
deasserts at (threshold - hysteresis). 0 0…10,000,000
22 Real Assert Delay
Seconds 8 The amount of time to delay the output action after a setpoint trigger occurs. Minimum equals
realtime update rate setting. 0 0.000…3600
23 Real Deassert Delay
Seconds 8 The amount of time to delay deassertion after the setpoint trigger releases. Minimum equals
realtime update rate setting. 0 0.000…3600
24 Real Parameter
Selection 9 Selection of the input parameter from the Setpoint Parameter Selection List . 0 0…105
25 Real Input Reference
Selection 9 Selects the type of input conditioning for non boolean parameters.
0 = Absolute Value 0 0
26 Real Test Condition 9 0 = Disabled
1 = Less Than
2 = Greater Than
3 = Equals 0 0…3
27 Real Evaluation Type 9 0 = Magnitude
1 = State
2 = Percent of Reference (not supported in the M5 model)
3 = Percent of Sliding Reference (not supported in the M5 model) 0 0…3
28 Real Threshold 9 The value, percent, or state that triggers the output action. 0 -10,000,000…
10,000,000
29 Real Hysteresis 9 The value in magnitude or percent of reference at which the output action is deasserted.
Example: A less than condition deasserts at (threshold + hysteresis), a greater than condition
deasserts at (threshold - hysteresis). 0 0…10,000,000
30 Real Assert Delay
Seconds 9 The amount of time to delay the output action after a setpoint trigger occurs. Minimum equals
realtime update rate setting. 0 0.000…3600
31 Real Deassert Delay
Seconds 9 The amount of time to delay deassertion after the setpoint trigger releases. Minimum equals
realtime update rate setting. 0 0.000…3600
Table 64 - Configuration.Setpoints_6_10 Data Table
Element
Number Type Tag Name Description Default Range
