Rockwell Automation Publication 1426-UM001F-EN-P - November 2013 237
PowerMonitor 5000 Unit Data Tables Appendix A
144 1 SINT KYZCommFaultMode The Default output state on communication loss defines the behavior
of the output if the power monitor experiences a loss of
communication.
0 = Last state/resume
1 = Last state/freeze
2 = De-energize/resume
3 = De-energize/freeze
4 = Local Control N/A 0…4
1 SINT Pad30 For alignment purpose
2 INT Pad31 For alignment purpose
148 1 SINT R1CommFaultMode The Default output state on communication loss defines the behavior
of the output if the power monitor experiences a loss of
communication.
0 = Last state/resume
1 = Last state/freeze
2 = De-energize/resume
3 = De-energize/freeze
4 = Local Control N/A 0…4
1 SINT Pad32 For alignment purpose
2 INT Pad33 For alignment purpose
152 1 SINT R2CommFaultMode The Default output state on communication loss defines the behavior
of the output if the power monitor experiences a loss of
communication.
0 = Last state/resume
1 = Last state/freeze
2 = De-energize/resume
3 = De-energize/freeze
4 = Local Control N/A 0…4
1 SINT Pad34 For alignment purpose
2 INT Pad35 For alignment purpose
156 1 SINT R3CommFaultMode The Default output state on communication loss defines the behavior
of the output if the power monitor experiences a loss of
communication.
0 = Last state/resume
1 = Last state/freeze
2 = De-energize/resume
3 = De-energize/freeze
4 = Local Control N/A 0…4
1 SINT Pad36 For alignment purpose
2 INT Pad37 For alignment purpose
Table 44 - Configuration.Instance Data Table
Start
Byte Size Type Tag Name Description Units Range
