320 Rockwell Automation Publication 1426-UM001F-EN-P - November 2013
Appendix A PowerMonitor 5000 Unit Data Tables
Statistics.Logging
Table 125 - Table Properties
CIP Instance Number 833
PCCC File Number N42
No. of Elements 20
Length in Words 20
Data Type Int16
Data Access Read Only
Table 126 - Statistics.Logging Data Table
Element
Number Type Tag Name Description Range
0 Int16 Number of Unit Event Log Records On a read of this table the value of this parameter is the number of Unit Event Records
available. This log is returned only by using the incremental return method. 0…100
1 Int16 Number of Time of Use Log Records On a read of this table the value of this parameter is the number of Time of Use Log
Records available. 1 is the current record being updated before logging. 0…13
2 Int16 Number of Load Factor Log Records On a read of this table the value of this parameter is the number of Load Factor Log
Records available. 1 is the current record being updated before logging. 0…13
3 Int16 Number of Setpoint Records On a read of this table the value of this parameter is the number of setpoint event records
available. 0…100
4 Int16 Number of Alarm Records On a read of this table the value of this parameter is the number of Alarm event records
available. 0…100
5 Int16 Number of Energy Log Records x1000 On a read of this table the value of this parameter is the x1000 number of Energy Log
Records available. 0…30,000
6 Int16 Number of Energy Log Records x1 On a read of this table the value of this parameter is the x1 number of Energy Log Records
available. 0…999
7 Int16 Number of Data Log Records x1000 On a read of this table the value of this parameter is the x1000 number of data log records
available. 0…30,000
8 Int16 Number of Data Log Records x1 On a read of this table the value of this parameter is the x1 number of data log records
available. 0…999
9 Int16 Number of Data Log Files Total Data Log files that have been saved 0…256
10 Int16 Number of Energy Log Files Total Energy Log files that have been saved 0…256
11 Int16 Number of Trigger Data Records On a read of this table the value of this parameter is the number of Trigger data records
available. 0…3600
12 Int16 Number of Trigger Data Files Total trigger data files have been saved 0…60
13 Int16 Number of Waveform Cycles On a read of this table the value of this parameter is the number of waveform data cycles
available. 0…21600
14 Int16 Number of Waveform Files Total waveform files have been saved 0…256
15 Int16 Number of Power Quality Records On a read of this table the value of this parameter is the number of power quality records
available. 0…100
16…19 Int16 Reserved Reserved for future use. 0
