PowerMonitor 5000 Unit Data Tables
48
4
Real
V1ToV2Voltage
V1 to V2 true RMS voltage
V
0…9.999E15
52
4
Real
V2ToV3Voltage
V2 to V3 true RMS voltage
V
0…9.999E15
56
4
Real
V3ToV1Voltage
V3 to V1 true RMS voltage
V
0…9.999E15
60
4
Real
AvgVToVVoltage
Average of V1_V2, V2_V3 and V3_V1.
V
0…9.999E15
64
4
Real
I1Current
I1 true RMS amps
A
0…9.999E15
68
4
Real
I2Current
I2 true RMS amps
A
0…9.999E15
72
4
Real
I3Current
I3 true RMS amps
A
0…9.999E15
76
4
Real
I4Current
I4 true RMS amps
A
0…9.999E15
80
4
Real
IAvgCurrent
Average I1, I2 and I3 amps.
A
0…9.999E15
84
4
Real
LineFreq
Last Line Frequency Calculated.
Hz
0.0…70.0
88
4
Real
Total_kW
L1, L2 and L3 kW Total.
kW
-9.999E15…9.999E15
92
4
Real
Total_kVAR
L1, L2 and L3 kVAR Total.
kVAR
-9.999E15…9.999E15
96
4
Real
Total_kVA
L1, L2 and L3 kVA Total.
kVA
0…9.999E15
100
4
Real
TotalTruePF
Total L1, L2 and L3 True Power Factor.
%
0.00…100.00
104
4
Real
TotalDisplacementPF
Total of L1, L2 and L3 Displacement Power Factor.
%
0.00…100.00
108
4
Real
AvgTHD_VToVN_IEEE
Average V1/V2/V3 to N IEEE Total Harmonic Distortion
%
0.00…100.00
112
4
Real
AvgTHD_VToV_IEEE
Average IEEE THD for V1-V2, V2-V3, V3-V1
%
0.00…100.00
116
4
Real
AvgTHD_Current_IEEE
Average I1/I2/I3 IEEE Total Harmonic Distortion
%
0.00…100.00
120
4
Real
AvgTHD_VToVN_IEC
Average V1/V2/V3 to N IEC Total Harmonic Distortion
%
0.00…100.00
124
4
Real
AvgTHD_VToV_IEC
Average IEC THD for V1-V2, V2-V3, V3-V1
%
0.00…100.00
128
4
Real
AvgTHD_Current_IEC
Average I1/I2/I3 IEC Total Harmonic Distortion
%
0.00…100.00
132
4
Real
VoltagePercentUnbalance
Voltage percent unbalance
%
0.00…100.00
136
4
Real
CurrentPercentUnbalance
Current percent unbalance
%
0.00…100.00
140
4
Real
S1ScaledCount_xM
Status 1 count times 1000000
xM
0…9,999,999
144
4
Real
S1ScaledCount_x1
Status 1 count times 1
x1
0…999,999
148
4
Real
S2ScaledCount_xM
Status 2 count times 1000000
xM
0…9,999,999
152
4
Real
S2ScaledCount_x1
Status 2 count times 1
x1
0…999,999
156
4
Real
S3ScaledCount_xM
Status 3 count times 1000000
xM
0…9,999,999
160
4
Real
S3ScaledCount_x1
Status 3 count times 1
x1
0…999,999
164
4
Real
S4ScaledCount_xM
Status 4 count times 1000000
xM
0…9,999,999
168
4
Real
S4ScaledCount_x1
Status 4 count times 1
x1
0…999,999
172
4
Real
GWh
Net gigaWatt hours
GWh
+/- 0…9,999,999
176
4
Real
kWh
Net kiloWatt hours
kWh
+/- 0.000…999,999
180
4
Real
GVARH
Net gigaVAR hours
GVARh
+/- 0…9,999,999
184
4
Real
kVARh
Net kiloVAR hours
kVARh
+/- 0.000…999,999
188
4
Real
GVAh
Total gigaVA hours
GVAh
0.000…9,999,999
192
4
Real
kVAh Total
kiloVA
hours
kVAh
0.000…999,999
196
4
Real
GAh
Total giga Ampere hours
GAh
0.000…9,999,999
200
4
Real
kAh
Total kilo Ampere hours
kAh
0.000…999,999
Table 40 - ScheduledData.Input Data Table
Start
Byte
Size Type
Tag
Name
Description
Units
Range
