Rockwell Automation 1426 PowerMonitor 5000 Unit User Manual
Page 276
276
Rockwell Automation Publication 1426-UM001F-EN-P - November 2013
Appendix A
PowerMonitor 5000 Unit Data Tables
8
Int16
Setpoint Output
5 Input Source
Selects the source for output. Setpoint or gate output state.
0 = No source
1 = Setpoint1
2 = Setpoint 2…
20 = Setpoint 20
21 = Level1_G1 ...
30 = Level1_G10
5
0…10 (M5)
0…30 (M6)
9
Int16
Setpoint Output
5 Action
Selects the output action to perform when setpoint is asserted. See the
. 0
0…19 (M5)
0…30 (M6)
10
Int16
Setpoint Output
6 Input Source
Selects the source for output. Setpoint or gate output state.
0 = No source
1 = Setpoint1
2 = Setpoint 2…
20 = Setpoint 20
21 = Level1_G1 ...
30 = Level1_G10
6
0…10 (M5)
0…30 (M6)
11
Int16
Setpoint Output
6 Action
Selects the output action to perform when setpoint is asserted. See the
. 0
0…19 (M5)
0…30 (M6)
12
Int16
Setpoint Output
7 Input Source
Selects the source for output. Setpoint or gate output state.
0 = No source
1 = Setpoint1
2 = Setpoint 2…
20 = Setpoint 20
21 = Level1_G1 ...
30 = Level1_G10
7
0…10 (M5)
0…30 (M6)
13
Int16
Setpoint Output
7 Action
Selects the output action to perform when setpoint is asserted. See the
. 0
0…19 (M5)
0…30 (M6)
14
Int16
Setpoint Output
8 Input Source
Selects the source for output. Setpoint or gate output state.
0 = No source
1 = Setpoint1
2 = Setpoint 2…
20 = Setpoint 20
21 = Level1_G1 ...
30 = Level1_G10
8
0…10 (M5)
0…30 (M6)
15
Int16
Setpoint Output
8 Action
Selects the output action to perform when setpoint is asserted. See the
. 0
0…19 (M5)
0…30 (M6)
16
Int16
Setpoint Output
9 Input Source
Selects the source for output. Setpoint or gate output state.
0 = No source
1 = Setpoint1
2 = Setpoint 2…
20 = Setpoint 20
21 = Level1_G1 ...
30 = Level1_G10
9
0…10 (M5)
0…30 (M6)
17
Int16
Setpoint Output
9 Action
Selects the output action to perform when setpoint is asserted. See the
. 0
0…19 (M5)
0…30 (M6)
Table 72 - Configuration.Setpoint_Outputs Data Table
Element
Number
Type
Tag Name
Description
Default
Range
