Rockwell Automation Publication 1426-UM001F-EN-P - November 2013 339
PowerMonitor 5000 Unit Data Tables Appendix A
LoggingResults.TOU.Log
Table 149 - Table Properties
CIP Instance Number 854
PCCC File Number F63
No. of Elements 38
Length in Words 76
Data Type Real
Data Access Read Only
Table 150 - LoggingResults.TOU.Log Data Table
Element
Number Type Tag Name Description Units Range
0 Real TOU_Record_Number The record number of the log. Record 0 is always the current record
before being logged 1…13
1 Real TOU_ Start_Date The Date this record was started YYMMDD 0…999999
2 Real TOU_End_Date The Date this record was ended YYMMDD 0…999999
3 Real Off_Peak_GWh_Net Net Off Peak gigawatt hours GWh ±0…9,999,999
4 Real Off_Peak_kWh_Net Net Off Peak kilowatt hours kWh ±0.000…999,999
5 Real Off_Peak_kW_Demand Off Peak Demand for kilowatts kW ±0.000…9,999,999
6 Real Mid_Peak_GWh_Net Net Mid Peak gigawatt hours GWh ±0…9,999,999
7 Real Mid_Peak_kWh_Net Net Mid Peak kilowatt hours kWh ±0.000…999,999
8 Real Mid_Peak_kW_Demand Mid Peak Demand for kilowatts kW ±0.000…9,999,999
9 Real On_Peak_GWh_Net Net On Peak gigawatt hours GWh ±0.000…9,999,999
10 Real On_Peak_kWh_Net Net On Peak kilowatt hours kWh ±0…999,999
11 Real On_Peak_kW_Demand On Peak Demand for kilowatts kW ±0.000…9,999,999
12 Real Off_Peak_GVARh_Net Net Off peak gigaVAR hours GVARh ±0…9,999,999
13 Real Off_Peak_kVARh_Net Net Off Peak kiloVAR hours kVARh ±0.000…999,999
14 Real Off_Peak_kVAR_Demand Off Peak Demand for kiloVAR kVAR ±0.000…9,999,999
15 Real Mid_Peak_GVARh_Net Net Mid Peak gigaVAR hours GVARh ±0…9,999,999
16 Real Mid_Peak_kVARh_Net Net Mid Peak kiloVAR hours kVARh ±0.000…999,999
17 Real Mid_Peak_kVAR_Demand Mid Peak Demand for kiloVAR kVAR ±0.000…9,999,999
18 Real On_Peak_GVARh_Net Net On Peak gigaVAR hours GVARh ±0.000…9,999,999
19 Real On_Peak_kVARh_Net Net On Peak kiloVAR hours kVARh ±0…999,999
20 Real On_Peak_kVAR_Demand On Peak Demand for kiloVAR kVAR ±0.000…9,999,999
21 Real Off_Peak _GVAh_Net Net Off peak gigaVA hours GVAh 0…9,999,999
22 Real Off_Peak_kVAh_Net Net Off Peak kiloVA hours kVAh 0.000…999,999
23 Real Off_Peak_kVA_Demand Off Peak Demand for kiloVA kVA 0.000…9,999,999
24 Real Mid_Peak_GVAh_Net Net Mid Peak gigaVA hours GVAh 0…9,999,999
25 Real Mid_Peak_kVAh_Net Net Mid Peak kiloVA hours kVAh 0.00…99,999
26 Real Mid_Peak_kVA_Demand Mid Peak Demand for kiloVA kVA 0.000…9,999,999
27 Real On_Peak_GVAh_Net Net On Peak gigaVA hours GVAh 0.000…9,999,999
