FR[N] - Follower Ratio
Purpose:
FR[1] defines the follower ratio for current (UM=1).
FR[2] defines the follower ratio for velocity (UM=2).
FR[3] defines the follower ratio for position (UM=3, 5).
When UM=1, the auxiliary reference is composed of the analog input and external
PWM signals. The FR[1] parameter scales the ratio between the Duty Cycle of the
PWM signal and the reference to the current loop (UM=1, RM=1). FR[1] may be
changed on-the-fly at any time.
When UM=2, the auxiliary reference is composed of the analog input and the auxiliary
feedback readout or external PWM signal.
FR[2] can be used as a follower ratio of the master motor’s quadrature encoder or as a
follower ratio of the PWM Duty.
When UM=3 or UM=5, the auxiliary reference is derived from the auxiliary feedback
readout. The FR[3] parameter scales the ratio between the auxiliary feedback position
and the reference to the position loop (UM=3, 4, 5, RM=1, EM[1]=0), or the input to the
ECAM table (UM=3, 4, 5, RM=1, EM[1]=1, 2).
FR[3] may be changed on-the-fly at any time. For EM[1]=0 (follower) and EM[1]=2
(cyclical ECAM), changing FR[3] does not imply an abrupt change to the external
position controller reference. For EM[1]=1 (linear ECAM), changing FR[3] does imply
an abrupt change in the external position controller reference.
FR[3] can be modified without a motion jump when the software reference is not
active (MS<1). Then the software position reference is corrected to avoid a possible
motor jump.
Attributes:
Type: Parameter,
Real
Source:
Program, RS-232, CANopen
Restrictions: MO=0:
none
MO=1: RM=1 and MS<2
Default value:
1 (RS), Non-volatile
Range: [-32,000…32,000]
Index range:
[1, 2, 3]
Unit modes:
UM=1, 2, 3, 5
Activation: Immediate
See also:
PY
,
RM
,
YM[N]
,
YA[N], PW[N]
Application notes:
The Position Reference Generator
The External Position Reference Generator
