SD - Stop Deceleration
Purpose:
Defines the deceleration in counts/second
2 used to stop motion in case of emergency.
In addition, SD defines the acceleration limit for the combination of software and
external reference commands.
Position-controlled motions cannot be stopped abruptly, because:
The discontinuity in the reference speed may produce position errors in excess of
ER[3]. This cuts the motor drive to freewheeling, which may be a safety problem with
high inertia or fast-moving loads.
If the maximum allowed acceleration value (GS[9]) is not correctly set, generating a
large position error can destabilize the position controller.
The SD parameter must be defined as the largest deceleration in which the motor can
accelerate/decelerate to the load.
The SD acceleration is applied in the following cases:
An ST command or hardware stop command (refer to the IL[N] command).
Data underflow in a PT or PVT motion.
Detection of a limit switch or an abort switch.
Attributes: Type: Parameter, Integer
Source: Program, RS-232, CANopen
Restrictions: MO=0
Default value:
1,000,000,000 (RS), Non-volatile
Range: Stop deceleration range
Unit modes: UM=2, 3, 4, 5
Activation: MO=1
SimplIQ:
Modified (range extended)
See also:
AC , DC , ST
Application notes:
The Position Reference Generator
Unit mode 2: Speed control
