Chapter 14: Diagnostics Commands
228
Figure 44. DIAGNOSTICS SHOW BOOTLOADER Command
The fields are defined here:
Chassis
Chassis
Chassis
MAC
Master
ID
Name
Type
Address
Chassis
=======================================================================
0
AT-MCF2000
11:22:33:44:55:55
Yes
Slot ID
Module Name
Module Type
Bootloader Version
-----------------------------------------------------------------
M
AT-MCF2000M
v3.0.0
1
Reg 1 traf
AT-MCF2012LC
v3.0.0
2
Reg 2 traf
AT-MCF2012LC/1
v3.0.0
=======================================================================
1
ACT Traffic
11:22:33:44:22:22
No
AT-MCF2300
Slot ID
Module Name
Module Type
Bootloader Version
-----------------------------------------------------------------
1
Reg 7 traf
AT-MCF2012LC
v3.0.0
2
Reg 8 traf
AT-MCF2012LC
v3.0.0
3
Reg 9 traf
AT-MCF2012LC
v3.0.0
4
Reg 10 traf
AT-MCF2012LC
v3.0.0
=======================================================================
2
UJ Traffic
11:22:33:44:66:77
No
AT-MCF2000
Slot ID
Module Name
Module Type
Bootloader Version
-----------------------------------------------------------------
1
District 1
AT-MCF2012LC
v3.0.0
2
District 2
AT-MCF2012LC
v3.0.0
Table 26. DIAGNOSTICS SHOW BOOTLOADER Command
Parameter
Description
Chassis ID
Displays the ID number of a chassis. The range is 0 to 31. For
background information, refer to “Chassis ID Numbers” on
page 25.
Chassis Name
Displays the name of a chassis. To set the chassis name, refer
to “SYSTEM SET CHASSIS” on page 59.
Chassis Type
Displays the model name of a chassis.
MAC Address
Displays the MAC address of a chassis. When communicating
with a network, the AT-MCF2000M Management Module uses
this address as its own address.
