Chapter 8: Configuration File Commands
154
Figure 31. SNMP Configuration Section
This section accepts the SNMP SET command. For information on the
command, refer to “SNMP SET” on page 206
Blade Configuration
This section controls the operating parameters of the channels and ports
on a media converter module. A master configuration file has a separate
Blade Configuration section for each of the media converter modules in a
chassis or stack.
The section is prefaced with three header lines that identify the media
converter module controlled by the commands in the section. An example
is shown in Figure 32.
Figure 32. Blade Configuration Header
The Filename line identifies the name of the auxiliary configuration file
used to create that portion of the master file as well as the media converter
module controlled by the commands. The numbers in the filename identify
the module. The first number represents the chassis ID and the second
number the slot number. For example, the auxiliary configuration filename
“BM_0_2.cfg” in Figure 32 identifies the media converter module in slot 2
of the chassis with an ID number of 0.
The Model Type field specifies the model name of the media converter
module and the MAC Address specifies its MAC address.
Note
The header lines of a Blade Configuration section should not be
modified or deleted.
### SNMP Configuration
snmp set mgrip1=0.0.0.0
snmp set mgrip2=0.0.0.0
snmp set mgrip3=0.0.0.0
snmp set mgrip4=0.0.0.0
snmp set get-community=public
snmp set set-community=private
snmp set trap-community=public
## Filename: BM_0_2.cfg
## Model Type: AT-MCF2012LC
## MAC Address: 00:15:77:70:7A:2C
