62 Brocade Mobility 7131N-FGR Product Reference Guide
53-1001947-01
Configuring power settings
4
1. Select System Configuration -> Power Settings from the menu tree.
2. Refer to the following to assess the access point’s current power state. Once known, determine
how available power resources are applied to the access point’s radios.
NOTE
Within the Power Configuration field, an installation professional selects a power mode based on the
different power resources available to that access point’s SKU. For 3af and 3at, choose between
Default and Option as best suited to that Brocade Mobility 7131N-FGR Access Point hardware SKU.
For example, if Option is selected for 3af Power, and the access point is a dual radio model, the
following configuration is set:
LAN port ON (1000 BAST-T)
WAN port OFF
Radio 1 (2.4) on, 2x3 mode with maximum transmit power 18dBm
Radio 2 (5.0) on, 2x3 mode with maximum transmit power 18dBm
Contact Brocade Support if unsure of your access point’s optimal power management settings, go
to
http://www.brocade.com/support/
