Enabling Wireless LANs (WLANs)
5
RTS Threshold
RTS allows the Brocade Mobility 7131N-FGR Access Point to use
RTS (Request To Send) on frames longer than the specified length.
The default is 2341bytes.
Set RF QoS
Click the Set RF QoS button to display the Set RF QOS screen to
set QoS parameters for the radio. Do not confuse with the QoS
configuration screen used for a WLAN. The Set RF QoS screen
initially appears with default values displayed.
Select manual from the Select Parameter set drop-down menu to
edit the CW min and CW max (contention window), AIFSN
(Arbitrary Inter-Frame Space Number) and TXOPs Time for each
Access Category. These are the QoS policies for the 802.11a/n or
802.11b/g/n radio, not the QoS policies configured for the WLAN
(as created or edited from the Quality of Service Configuration
screen).
Brocade recommends only advanced users manually set these
values. If the type of data-traffic is known, use the drop-down
menu to select an option representative of the intended radio
band support. Wifi represents multimedia traffic, default is typical
data traffic and voice is for “Voice-Over-IP” supported wireless
devices.
Click OK to implement the selected QoS values and return to the
802.11a/n or 802.11b/g/n radio configuration screen. Clicking
Cancel reverts the screen to the last saved configuration.
