Viewing MU statistics summary
7
Viewing MU statistics summary
Use the MU Stats Summary screen to display overview statistics for mobile units (MUs) associated
with the Brocade Mobility 7131N-FGR Access Point. The MU List field displays basic information
such as IP Address and total throughput for each associated MU. The MU Stats screen is view-only
with no user configurable data fields. However, individual MUs can be selected from within the MU
Stats Summary screen to either ping to assess interoperability or display authentication statistics.
To view Brocade Mobility 7131N-FGR Access Point overview statistics for all of the MUs associated
to the Brocade Mobility 7131N-FGR Access Point:
1. Select Status and Statistics - > MU Stats from the Brocade Mobility 7131N-FGR Access Point
menu tree.
2. Refer to the MU List field to reference associated MU address, throughput and retry
information.
IP Address
Displays the IP address of each of the associated MU.
MAC Address
Displays the MAC address of each of the associated MU.
WLAN
Displays the WLAN name each MU is interoperating with.
Radio
Displays the name of the 802.11a/n or 802.11b/g/n radio each
MU is associated with.
T-put
Displays the total throughput in Megabits per second (Mbps) for
each associated MU.
ABS
Displays the Average Bit Speed (ABS) in Megabits per second
(Mbps) for each associated MU.
