Page 200: Settings

188
Brocade Mobility 7131N-FGR Product Reference Guide
53-1001947-01
Configuring VPN tunnels
6
4. Click Ok to return to the VPN screen. Click Apply to retain the settings made on the Auto Key
Settings screen.
5. Click Cancel to return to the VPN screen without retaining the changes made to this screen.
Configuring IKE key settings
The Internet Key Exchange (IKE) is an IPsec standard protocol used to ensure security for VPN
negotiation and remote host or network access. IKE provides an automatic means of negotiation
and authentication for communication between two or more parties. In essence, IKE manages
IPSec keys automatically for the parties.
To configure IKE key settings for the Brocade Mobility 7131N-FGR Access Point:
1. Select Network Configuration -> WAN -> VPN from the Brocade Mobility 7131N-FGR Access
Point menu tree.
2. Refer to the VPN Tunnel Config field, select the Auto (IKE) Key Exchange radio button and click
the IKE Settings button.
ESP Encryption
Algorithm
Use this menu to select the encryption and authentication
algorithms for this VPN tunnel.
•
3DES - Selects the 3DES algorithm. No keys are required to
be manually provided.
•
AES 128-bit - Selects the Advanced Encryption Standard
algorithm with 128-bit. No keys are required to be manually
provided.
•
AES 192-bit - Selects the Advanced Encryption Standard
algorithm with 192-bit. No keys are required to be manually
provided.
•
AES 256-bit - Selects the Advanced Encryption Standard
algorithm with 256-bit. No keys are required to be manually
provided.
ESP Authentication
Algorithm
This menu is only active when ESP with Authentication was
selected for the ESP type.
•
SHA1 - Enables Secure Hash Algorithm. No keys are required
to be manually provided.
