Brocade Mobility 7131N-FGR Product Reference Guide

549

53-1001947-01

Adaptive AP overview

10

To review a sample AAP configuration, see

“Sample switch configuration file for IPSec and

independent WLAN”

on page 557.

Adaptive AP switch failure

In the event of a switch failure, an AAP's independent WLAN continues to operate without
disruption. The AAP attempts to connect to other switches (if available) in background. Extended
WLANs are disabled once switch adoption is lost. When a new switch is discovered and a
connection is secured, an extended WLAN can be enabled.

If a new switch is located, the AAP synchronizes its configuration with the located switch once
adopted. If Remote Site Survivability (RSS) is disabled, the independent WLAN is also disabled in
the event of a switch failure.

Remote site survivability (RSS)

RSS can be used to turn off RF activity on an AAP if it loses adoption (connection) to the switch.

NOTE

For a dependant AAP, independent WLANs continue to beacon for three days in the absence of a
switch.

Adaptive mesh support

An AAP can extend existing mesh functionality to a switch managed network. All mesh APs are
configured and managed through the wireless switch. APs without a wired connection form a mesh
backhaul to a repeater or a wired mesh node and then get adopted to the switch. Mesh nodes with
existing wired access get adopted to the switch like a wired AAP.

Mesh AAPs apply configuration changes 300 seconds after the last received switch configuration
message. When the configuration is applied on the Mesh AAP, the radios shutdown and re-initialize
(this process takes less than 2 seconds), forcing associated MUs to be deauthenticated and the
Mesh link will go down. MUs are able to quickly associate, but the Mesh link will need to be
re-established before MUs can pass traffic. This typically takes about 90 to 180 seconds
depending on the size of the mesh topology.

NOTE

When mesh is used with AAPs, the "ap-timeout" value needs to be set to a higher value (for example,
180 seconds) so Mesh AAPs remain adopted to the switch during the period when the configuration
is applied and mesh links are re-established.

For an overview of mesh networking and how to configure an access point to support mesh, see

“Configuring mesh networking support”

on page 523.

RSS State

Independent WLANs

Extended WLANs

RSS Enabled

WLAN continues beaconing

WLAN continues beaconing but AP does allow
clients to associate on that WLAN

RSS Disabled

WLAN stops beaconing

WLAN stops beaconing
