60 Brocade Mobility 7131N-FGR Product Reference Guide
53-1001947-01
Configuring power settings
4
Radios at full power
The table below describes the maximum transmit power available to each radio (at varying data
rates) when the access point is receiving full DC power and is not compromised in its power budget.
These values should be viewed as the safe limit for the access point’s radio at full power and
should not be exceeded.
Radios at low power
The table below describes the maximum transmit power available to each radio (at varying data
rates) when the access point is receiving low DC power in either af or at mode.
CAUTION
Exceeding the limits listed below can cause damage to the access point or cause the radio to
operate unpredictably. Thus, these values should be viewed as the safe limit for the access
point’s radio and should not be exceeded in either af or at mode.
Rates (Mbps) MCS Indices EVM Bandwidth Maximum Transmit
Power 2.4 GHz Maximum Transmit
Power 5 GHz
1 -9 20MHz 23 NA
2 -9 20MHz 23 NA
5.5 -9 20MHz 23 NA
11 -9 20MHz 23 NA
6 -5 20MHz 23 20
9 -8 20MHz 23 20
12 -10 20MHz 23 20
18 -13 20MHz 23 20
24 -16 20MHz 22 20
36 -19 20MHz 22 19
48 -22 20MHz 21 18
54 -25 20MHz 20 17
MCS0/MCS8 -5 HT20/40 23 20
MCS1/MCS9 -10 HT20/40 23 20
MCS2/MCS10 -13 HT20/40 23 20
MCS3/MCS11 -16 HT20/40 23 19
MCS4/MCS12 -19 HT20/40 22 19
MCS5/MCS13 -22 HT20/40 22 18
MCS6/MCS14 -25 HT20/40 21 17
MCS7/MCS15 -28 HT20/40 20 17
