Brocade Mobility 7131N-FGR Access Point Product Reference Guide (Supporting software release 4.0.0.0-35GRN and later) User Manual
Page 148

136
Brocade Mobility 7131N-FGR Product Reference Guide
53-1001947-01
Enabling Wireless LANs (WLANs)
5
8. Refer to the Radius Configuration field to define a primary and secondary Radius server port
and shared secret password.
9. Click OK to save any changes to the Hotspot Configuration screen. Navigating away from the
screen without clicking Apply results in all changes to the screens being lost.
10. Click Cancel (if necessary) to undo any changes made. Cancel reverts the settings displayed on
the Hotspot Configuration screen to the last saved configuration.
Defining the Hotspot White List
To host a Login, Welcome or Fail page on the external Web server, the IP address of that Web server
should be in access point’s White List.
Enable Accounting
Select the Enable Accounting checkbox to enable a Radius
Accounting Server used for Radius authentication for a target
hotspot user.
Server Address
Specify an IP address for the external Radius Accounting server
used to provide Radius accounting for the hotspot. If using this
option, an internal Radius server cannot be used. The IP address
of the internal Radius server is fixed at 127.0.0.1 and cannot be
used for the external Radius server.
Radius Port
Specify the port on which the Radius accounting server is
listening.
Shared Secret
Specify a shared secret for accounting authentication for the
hotspot. The shared secret is required to match the shared secret
on the external Radius accounting server.
Timeout
Set the timeout value in seconds (1-255) used to timeout users
accessing the Radius Accounting server if they have not
successfully accessed the Accounting Server.
Retries
Define the number of retries (1-10) the user is allowed to access
the Radius Accounting Server if the first attempt fails.
The default is 1.
Select mode
Use the Select mode drop-down menu to define whether an
Internal or External server is to be used for the primary server.
Pri Server IP
Define the IP address of the primary Radius server. This is the
address of your first choice for Radius server.
Pri Port
Enter the TCP/IP port number for the server acting as the primary
Radius server. The default port is 1812.
Pri Secret
Enter the shared secret password used with the primary Radius
Server.
Sec Server IP
Define the IP address of the secondary Radius server. This is the
address of your second choice for Radius server.
Sec Port
Enter the TCP/IP port number for the server acting as the
secondary Radius server. The default port is 1812.
Sec Secret
Enter the shared secret password used with the secondary Radius
Server.
