26 Brocade Mobility 7131N-FGR Product Reference Guide
53-1001947-01
Power options
2
The 2.4 GHz antenna suite includes the following models:
NOTE
An additional adapter is required to use ML-2499-11PNA2-01 and ML-2499-BYGA2-01 model
antennae. Please contact Brocade for more information.
The 5 GHz antenna suite includes the following models:
For a more exhaustive overview of the antennas and associated components supported by the
Brocade access point family, refer to the Enterprise Wireless LAN Antenna Specification Guide
available at
http://www.brocade.com.
Power options
The power options for a Brocade Mobility 7131N-FGR Access Point include:
• 48-Volt Power Supply (Part No. 50-14000-247R)
CAUTION
A Brocade Mobility 7131N-FGR Access Point must use the 48-Volt Power Supply designed
specifically for use with the Brocade Mobility 7131N-FGR Access Point.
Part No. Antenna Type Approximate Gain (dBi)
ML-2499-11PNA2-01R Wide Angle Directional 8.5
ML-2499-HPA3-01R Omni-Directional Antenna 3.3
ML-2499-BYGA2-01R Yagi Antenna 13.9
ML-2452-APA2-01 Dual-Band 3/4
ML-2452-PTA2M3X3-2 Facade with 6 Element
Antenna Module 3/5
ML-2452-PTA3M3-036 3 Port MIMO Antenna 4.75/5.5
Part No. Antenna Type Approximate Gain (dBi)
ML-5299-WPNA1-01R Panel Antenna 13
ML-5299-HPA1-01R Wide-Band Omni-Directional
Antenna 5.0
ML-2452-APA2-01 Dual-Band 3/4
ML-2452-PTA2M3X3-2 Facade with 6 Element Antenna
Module 4.75/5.5
ML-2452-PTA3M3-036 3 Port MIMO Antenna 5/5
ML-2452-APA6J-01 Dipole 2.4GHz Peak Gain: -5.76dBi
5GHz Peak Gain:
band 1: -3.77dBi
band 2: -3.38dBi
band 3: -2.84dBi
band 4: -2.94dBi
