438

Brocade Mobility 7131N-FGR Product Reference Guide

53-1001947-01

System commands

8

BR7131N>admin(system.snmp.traps)> add

Adds SNMP trap entries.

Syntax

Example

admin(system.snmp.traps)>add v1v2 203.223.24.2 333 mycomm v1

admin(system.snmp.traps)>list v1v2c

----------------------------------------------------------------------

index

dest ip

dest port

community

version

----------------------------------------------------------------------

1

203.223.24.2

333

mycomm

v1

admin(system.snmp.traps)>add v3 201.232.24.33 555 BigBoss none md5

admin(system.snmp.traps)>list v3 all

index

: 1

destination ip

: 201.232.24.33

destination port

: 555

username

: BigBoss

security level

: none

auth algorithm

: md5

auth password

: ********

privacy algorithm

: des

privacy password

: ********

For information on configuring SNMP traps using the applet (GUI), see

“Configuring SNMP RF trap

thresholds”

on page 86.

ad
d

v1v
2

Adds an entry to the SNMP v1/v2 access list with the destination IP address set to , the
destination UDP port set to , the community string set to (1 to 31 characters), and the
SNMP version set to .

v3

Adds an entry to the SNMP v3 access list with the destination IP address set to , the destination
UDP port set to , the username set to (1 to 31 characters), and the authentication type
set to one of none, auth, or auth/priv.
The following parameters must be specified if is not none:

Authentication type set to md5 or sha1
Authentication password (8 to 31 chars)

The following parameters must be specified if is set to auth/priv:

Privacy algorithm set to des or aes
Privacy password (8 to 31 chars)
