Brocade Mobility 7131N-FGR Product Reference Guide
157
53-1001947-01
Configuring IP filtering
5
1. Select Network Configuration -> IP Filtering from the Brocade Mobility 7131N-FGR Access
Point menu tree.
When the IP Filtering screen is initially displayed, there are no default filtering policies, and they must
be created.
NOTE
With IP Filtering, users can only define a destination port, not a source port.
2. Click the Add button to define the attributes of a new IP Filtering policy. The following policy (or
filtering rule) attributes require definition.
Filter name
Create a name for the filter policy unique to its function in order to
differentiate it from others that may have somewhat similar
configurations.
Protocol
Specify the protocol used for the filter policy. The options are ALL,
TCP, UDP, ICMP, PIM, GRE, RSVP, IDP, PUP, EGP, IPIP, ESP, AH,
IGMP, IPVG, COMPR_H and RAW_IP. The protocol number can also
be used as the protocol name. This allows the use or protocols that
are not within the drop-down menu.
Port Start
Defines the socket number (or port) number representing the
beginning protocol port range either allowed or denied permission
to the target LAN1, LAN2 or WLAN.
Port End
Defines the socket number (or port) number representing the
ending protocol port range either allowed or denied permission to
the target LAN1, LAN2 or WLAN.
Src Start
Creates a range beginning source IP address to be either allowed
or denied IP packet forwarding. The source address is where the
packet originated. Setting the Src End value the same as the Src
Start allows or denies just this address without defining a range.
