564 Brocade Mobility 7131N-FGR Product Reference Guide
53-1001947-01
Radio characteristics
A
Radio characteristics
A Brocade Mobility 7131N-FGR Access Point has the following radio characteristics:
Country codes
The following list of countries and their country codes is useful when using the Brocade Mobility
7131N-FGR Access Point configuration file, CLI or the MIB to configure the access point:
Operating Channels All channels from 4920 MHz to 5825 MHz except channel
52 -64
Channels 1-13 (EU), Channels 1-11 (US/Canada)
Channel 14 (2484 MHz) Japan only
Actual operating frequencies depend on regulatory
Data Rates Supported 802.11g: 1,2,5.5,11,6,9,12,18,24,36,48, and 54Mbps
802.11a: 6,9,12,18,24,36,48, and 54Mbps
802.11n: MCS 0-15 up to 300Mbps
Wireless Medium Direct Sequence Spread Spectrum (DSSS),
Orthogonal Frequency Division Multiplexing (OFDM)
Spatial multiplexing (MIMO)
Network Standards 802.11a, 802.11b, 802.11g, 802.3, 802.11n (Draft 2.0)
Maximum Available
Transmit Power Maximum available conducted transmit power per chain: 2.4Ghz: + 23dBm
Maximum available conducted transmit power all chains: 2.4GHz: + 27.7dBm
Maximum available conducted transmit power per chain: 5.2Ghz: + 20 dBm
Maximum available conducted transmit power all chains: 5.2GHz: + 24.7dBm
Transmit Power
Adjustment 1dB increments
Antenna Configuration 2x3 or 3x3
Country Code Country Code
Argentina AR Mexico MX
Australia AU Moldova MD
Austria AT Morocco MA
Bahamas BS Nambia NA
Bahrain BH Netherlands NL
Barbados BB Netherlands Antilles AN
Belarus BY New Zealand NZ
Belgium BE Nicaragua NI
Bermuda BM Norfolk Island NF
Bolivia BO Northern Mariana Islands MP
Botswana BW Norway NO
Botznia-Herzegovina BA Oman OM
