Viewing wireless statistics
7
1. Select Status and Statistics -> Wireless Stats -> WLANx Stats (x = target WLAN) from the
Brocade Mobility 7131N-FGR Access Point menu tree.
2. Refer to the Information field to view specific WLAN address, MU and security scheme
information for the WLAN selected from the Brocade Mobility 7131N-FGR Access Point menu
tree.
3. Refer to the Traffic field to view performance and throughput information for the WLAN
selected from the Brocade Mobility 7131N-FGR Access Point menu tree.
ESSID Displays the Extended Service Set ID (ESSID) for the target WLAN.
Radio/s Displays the name of the 802.11a/n or 802.11b/g/n radio the
target WLAN is using for Brocade Mobility 7131N-FGR Access
Point transmissions.
Authentication Type Displays the authentication type defined for the WLAN. If the
authentication type does not match the desired scheme for the
WLAN or needs to be enabled, see
“Enabling authentication and
encryption schemes” on page 164.
Encryption Type Displays the encryption method defined for the WLAN. If the
encryption type does not match the desired scheme for the WLAN
or needs to be enabled, see
“Enabling authentication and
encryption schemes” on page 164.
Num. Associated MUs Displays the total number of MUs currently associated with the
WLAN. If this number seems excessive, consider segregating MU’s
to other WLANs if appropriate.
