4. Click the Ping button to begin transmitting packets to the specified MU address.
Refer to the Number of Responses value to assess the number of responses from the MU
versus the number of ping packets transmitted by the access point. Use the ratio of packets
sent versus the number of packets received the link quality between the MU and the access
point.
Click the OK button to exit the Echo Test screen and return to the MU Stats Summary screen.
Where to go from here?
Once basic connectivity has been verified, the Brocade Mobility 7131N-FGR Access Point can be
fully configured to meet the needs of the network and the users it supports. Refer to the following:
•
For detailed information on Brocade Mobility 7131N-FGR Access Point device access, SNMP
settings, network time, importing/exporting device configurations and device firmware
updates, see
•
For detailed information on configuring Brocade Mobility 7131N-FGR Access Point LAN
interface (subnet) and WAN interface see,
•
For detailed information on configuring specific encryption and authentication security
schemes for individual Brocade Mobility 7131N-FGR Access Point WLANs, see
•
To view detailed statistics on the Brocade Mobility 7131N-FGR Access Point and its associated
MUs, see
Station Address
The station address is the IP address of the target MU. Refer to
the MU Stats Summary screen for associated MU IP address
information.
Number of pings
Defines the number of packets to be transmitted to the MU. The
default is 100.
Packet Length
Specifies the length of each packet transmitted to the MU
during the test. The default length is 100 bytes.
