Enabling Wireless LANs (WLANs)
5
Power Level
Use the drop-down menu to defines the transmit power of the
802.11a/n or 802.11b/g/n antenna(s). The values are expressed
in dBm and mW.
Set Rates
Click the Set Rates button to define minimum and maximum data
transmit rates for the radio.
Use the Basic Rates drop-down menu to select the rates available
for either the 2.4 GHz or 5 GHz radio band. The menu options
differ, based on the radio band.
For 2.4 GHz, the following options are available:
•
1 and 2 Mbps
•
1, 2, 5.5 and 11 Mbps (default setting)
•
1, 2, 5.5, 11 and 6, 12, 24 Mbps
•
1, 2, 5.5, 11 and 6, 12, 24 Mbps and MCS 0-7
•
6, 12 and 24 Mbps
•
6, 12 and 24 Mbps and MCS 0-7
•
MCS 0-7
For 5 Ghz, the following options are available:
•
6, 12 and 24 Mbps
•
6, 12 and 24 Mbps and MCS 0-7
•
MCS 0-7
When a basic rate option is selected (from the drop-down menu),
the rates are automatically selected and grayed out in the
Supported Rates radio boxes. Select remaining rates as needed
for additional supported rates.
Enable the Support Short Guard Interval checkbox to set a guard
interval (for interference protection) for 20 MHz and 40 MHz
channel widths. When enabled, the AP’s radio defines values to
enable a packet to be transmitted with guard interval based on the
configuration and capabilities of associated clients. Clients can
associate to an access point regardless of whether they support a
short guard interval.
If supporting 802.11n, select a Supported MCS index (0-15). Set a
MCS (modulation and coding scheme) in respect to the radio’s
channel width and guard interval. A MCS defines (based on RF
channel conditions) an optimal combination of 8 data rates,
bonded channels, multiple spatial streams, different guard
intervals and modulation types. MUs can associate as long as they
support basic MCS (as well as non-11n basic rates).
Click OK to implement the selected rates and return to the radio
configuration screen. Clicking Cancel reverts the Set Rates screen
to the last saved configuration.
