Viewing LAN statistics
7
3. Refer to the Received field to view data received over the Brocade Mobility 7131N-FGR Access
Point LAN port.
4. Refer to the Transmitted field to view statistics transmitted over the Brocade Mobility
7131N-FGR Access Point LAN port.
Speed
The LAN 1 or LAN 2 connection speed is displayed in Megabits per
second (Mbps), for example, 54Mbps. If the throughput speed is
not achieved, examine the number of transmit and receive errors,
or consider increasing the supported data rate. To change the data
rate of the 802.11a/n or 802.11b/g/n radio, see
802.11a/n or 802.11b/g/n radio”
Duplex
Displays whether the current LAN connection is full or half duplex.
WLANs Mapped
The WLANs Mapped table lists the WLANs mapped to this LAN
(either LAN1 or LAN2) as their LAN interface.
RX Packets
RX packets are data packets received over the Brocade Mobility
7131N-FGR Access Point LAN port. The number is a cumulative
total since the LAN connection was last enabled or the Brocade
Mobility 7131N-FGR Access Point was last restarted. To begin a
new data collection, see
RX Bytes
RX bytes are bytes of information received over the LAN port. The
value is a cumulative total since the LAN connection was last
enabled or the Brocade Mobility 7131N-FGR Access Point was last
restarted. To begin a new data collection, see
RX Errors
RX errors include dropped data packets, buffer overruns, and
frame errors on inbound traffic. The number of RX errors is a total
of RX Dropped, RX Overruns and RX Carrier errors. Use this
information to determine performance quality of the current LAN
connection.
RX Dropped
The RX Dropped field displays the number of data packets failing
to reach the LAN port. If this number appears excessive, consider
a new connection to the device.
RX Overruns
RX overruns are buffer overruns on the Brocade Mobility
7131N-FGR Access Point LAN port. RX overruns occur when
packets are received faster than the LAN connection can handle
them. If RX overruns are excessive, consider reducing the data
rate, for more information, see
RX Frame
The RX Frame field displays the number of TCP/IP data frame
errors received.
