Brocade Mobility 7131N-FGR Access Point Product Reference Guide (Supporting software release 4.0.0.0-35GRN and later) User Manual
Page 219

Brocade Mobility 7131N-FGR Product Reference Guide
207
53-1001947-01
Configuring user authentication
6
CAUTION
If using a proxy server for Radius authentication, the Data Source field within the Radius server
screen must be set to Local. If set to LDAP, the proxy server will not be successful when
performing the authentication. To verify the existing settings, see
“Configuring the Radius Server”
CAUTION
When configuring the credentials of an MU, ensure its login (or user) name is a Fully Qualified
Domain Name (FQDN), or it cannot be authenticated by the access point’s proxy server. For
example; [email protected].
To configure the proxy Radius server for the Brocade Mobility 7131N-FGR Access Point:
1. Select System Configuration -> User Authentication -> RADIUS Server -> Proxy from the menu
tree.
CAUTION
Ensure IPSec has been properly configured to protect communications with the external Proxy
server. Changes will not be applied otherwise.
2. Refer to the Proxy Configuration field to define the proxy server’s retry count and timeout
values.
