Brocade Mobility 7131N-FGR Access Point Product Reference Guide (Supporting software release 4.0.0.0-35GRN and later) - Manual (Page 253)

Brocade Mobility 7131N-FGR Product Reference Guide 241
53-1001947-01
Viewing known access point statistics
7
1. Select Status and Statistics -> Known AP Stats from the Brocade Mobility 7131N-FGR Access
Point menu tree.
The Known AP Statistics screen displays the following information:
2. Click the Clear Known AP Stats button to reset each of the data collection counters to zero in
order to begin new data collections.
3. Click the Details button to display access point address and radio information.
IP Address The network-assigned Internet Protocol address of the located AP.
MAC Address The unique 48-bit, hard-coded Media Access Control address,
known as the devices station identifier. This value is hard coded at
the factory by the manufacturer and cannot be changed.
MUs The number MUs associated with the located Brocade Mobility
7131N-FGR Access Point.
Unit Name Displays the name assigned to the Brocade Mobility 7131N-FGR
Access Point using the System Settings screen. For information on
changing the unit name, see
“Configuring system settings” on
page 56.
