Brocade Mobility 7131N-FGR Product Reference Guide
117
53-1001947-01
Configuring WAN settings
5
4. Configure the Port Forwarding screen to modify the following:
5. Click OK to return to the NAT screen. Within the NAT screen, click Apply to save any changes
made on the Port Forwarding screen.
Add
Click Add to create a local map that includes the name, transport
protocol, start port, end port, IP address and Translation Port for
incoming packets.
Delete
Click Delete to remove a selected local map entry.
Name
Enter a name for the service being forwarded. The name can be
any alphanumeric string and is used for identification of the
service.
Transport
Use the Transport pull-down menu to specify the transport protocol
used in this service. The choices are ALL, TCP, UDP, ICMP, AH, ESP,
and GRE.
Start Port and End Port
Enter the port or ports used by the port forwarding service. To
specify a single port, enter the port number in the Start Port area.
To specify a range of ports, use both the Start Port and End Port
options to enter the port numbers. For example, enter 110 in the
Start Port field and 115 in the End Port field.
IP Address
Enter the numerical (non DNS name) IP address to which the
specified service is forwarded. This address must be within the
specified NAT range for the associated WAN IP address.
Translation Port
Specify the port number used to translate data for the service
being forwarded.
Forward all unspecified
ports to
Use the Forward all unspecified ports to checkbox to enable port
forwarding for incoming packets with unspecified ports. In the
adjacent area, enter a target forwarding IP address for incoming
packets. This number must be within the specified NAT range for
the associated WAN IP address.
