Brocade Mobility 7131N-FGR Access Point Product Reference Guide (Supporting software release 4.0.0.0-35GRN and later) User Manual
Page 199

Brocade Mobility 7131N-FGR Product Reference Guide
187
53-1001947-01
Configuring VPN tunnels
6
3. Configure the Auto Key Settings screen to modify the following:
Use Perfect Forward
Secrecy
Forward secrecy is a key-establishment protocol guaranteeing the
discovery of a session key or long-term private key does not
compromise the keys of other sessions. Select Yes to enable
Perfect Forward Secrecy. Select No to disable Perfect Forward
Secrecy.
Security Association
Life Time
The Security Association Life Time is the configurable interval used
to timeout association requests that exceed the defined interval.
The available range is from 300 to 65535 seconds. The default is
300 seconds.
AH Authentication
AH provides data authentication and anti-replay services for the
VPN tunnel. Select the desired authentication method from the
drop-down menu.
•
None - Disables AH authentication. No keys are required to be
manually provided.
•
SHA1 - Enables Secure Hash Algorithm 1. No keys are
required to be manually provided.
ESP Type
ESP provides packet encryption, optional data authentication and
anti-replay services for the VPN tunnel. Use the drop-down menu
to select the ESP type.
•
ESP - Enables ESP for this tunnel.
•
ESP with Authentication - Enables ESP with authentication.
