4. RC Gateway Function setting
68
(2) MSEP
The setting of MSEP is to be carried out with being connected to PC with the enclosed cable, and with
using “Gateway Parameter Setting Tool” and “RC PC Software”.
Set the MODE switch on the front panel of MSEP main machine to MANU side.
[Preparation] Connection to PC
[Procedure 1] Gateway Parameter Setting Tool Startup
1) Start up ROBONET Gateway Parameter Setting Tool, select MSEP GW and click on
OK button.
2) MSEP (unit number) becomes available to select. Select the unit number to be
connected and click on the OK button. If MSEP is connected to PC one to one, select
0.
PC Software Accessory Cable
(RS232CœRS485 conversion unit)
or
(USBœRS485 with converter adapter)
MODE switch
TP port
(SIO)
