6. Appendix
6.1 List of Additional I/O Parameters
The shaded parameters in bold are new parameters.
For the parameters in the X-SEL controller, refer to the operation manual for the X-SEL controller.
No. Parameter name
Default
value
(reference)
Input range Unit Remarks
213
Free-for-User SIO
Channel 2 Attribute 1
(mounting standard)
28100001
H
0
H
to
FFFFFFFF
H
[8] [7] [6] [5] [4] [3] [2] [1]
H
m Enter as HEX
values of 0 to F.
[8] Bits 28 to 31: Baud rate type for RS232C
communication
(0: 9.6 / 1: 19.2 / 2: 38.4
3: 57.6 / 4: 76.8 / 5: 115.2 kbps)
[7] Bits 24 to 27: Data length for RS232C
communication (7 or 8)
[6] Bits 20 to 23: Stop bit length for RS232C
communication (1 or 2)
[5] Bits 16 to 19: Parity type for RS232C
communication (0: None / 1: Odd / 2: Even)
[4] Bits 12 to 15: Operation mode
(0: RS232C / 1: RC gateway)
* Only channel 2 is valid in the RC gateway
mode.
[3] Bits 8 to 11: (Reserved.)
[2] Bits 4 to 7: (Reserved.)
[1] Bits 0 to 3: SIO use selection
(0: Not used / 1: Used)
214
Free-for-User SIO
Channel 2 Attribute 2
(mounting standard)
00000001
H
0
H
to
FFFFFFFF
H
[8] [7] [6] [5] [4] [3] [2] [1]
H
m Enter as HEX
values of 0 to F.
[8] [7] Bits 24 to 31: (Reserved.)
[6] Bits 20 to 23: Change prohibited.
[5] Bits 16 to 19: Character transmission interval
[msec]
[4] Bits 12 to 15: Communication method
(0: Full-duplex / 1: Half-duplex)
[3] Bits 8 to 11: Send operation type for
half-duplex communication
(0: Do not check CTS-ON at send /
1: Check CTS-ON at send)
[2] [1] Bits 0 to 7: Minimum receive o send
switching delay time in half-duplex
communication [msec]
