4. RC Gateway Function setting
60
4.3 Settings for Fieldbus type
4.3.1 Master (X-SEL) Setting 2
X-SEL PC software is used in the setting process.
[Procedure 1] Interface setting
This parameter is set at the shipment from the factory, and is available only for reference.
No. I/O Parameter Unit Set Value
Default
factory setting
225 Network I/F Module Control -
000H
: RC Gateway
Fieldbus board not used
5H
: Mounting RC Gateway
Fieldbus board to network
dedicated slot
500H
: Mounting RC Gateway
Fieldbus board to I/O 1
Installed
before
delivery in
accordance
with mounted
position.
[Procedure 2] Fieldbus type valid setting
Set whether to valid/invalid RC Gateway Fieldbus Function. Set the following parameter to
“1”.
No. I/O Parameter Name Unit Set Value
Default
factory setting
431 Fieldbus Master Function Select -
0: RC Gateway
Invalid Fieldbus Function
1: RC Gateway
Valid Fieldbus Function
0H
