3. W
iring
30
SIO communication components required by the configuration shown in Example 1
Name Model Quantity
SIO converter RCB-TU-SIO-A or B 1
Power I/O Cable for SIO type CB-ERC2-PWBIO-ƑƑƑ 1
Network connection cable CB-ERC2-CTL001 1
Purchased
from IAI
Controller link cable CB-RCB-CTL002 2
RS232C cross cable (D-sub, 9-pin) (Commercial product) 1
Recommended cables 1, 2 HK-SB/20276 (Taiyo Cabletec Corporation) Lm
3-1473562-4 (AMP) 1
Provided by
the customer e-CON connector
4-1473562-4 (AMP) 1
The above table only lists the components required for SIO communication. The customer must provide
other components that are required, such as a safety circuit, power supply and cables for their connection.
ƑƑƑ in the table indicates the cable length. Example: 050 = 5 m
