6.
Appendix
128
I/O parameters (The shaded parameters in bold are new parameters: Continued)
No. Parameter name
Default
value
(reference)
Input range Unit Remarks
221
Free-for-User SIO
Channel 2 Attribute 9
(mounting standard)
00000000
H
0
H
to
FFFFFFFF
H
222
Free-for-User SIO
Channel 2 Attribute 10
(mounting standard)
00000000
H
0
H
to
FFFFFFFF
H
223
Free-for-User SIO
Channel 2 Attribute 11
(mounting standard)
00000000
H
0
H
to
FFFFFFFF
H
224
Free-for-User SIO
Channel 2 Attribute 12
(mounting standard)
00000000
H
0
H
to
FFFFFFFF
H
225 Network I/F
Module Control
00000000
H
0
H
to
FFFFFFFF
H
[8] [7] [6] [5] [4] [3] [2] [1]
H
m Enter as HEX
values of 0 to F.
Set [8] to [4] to 0.
[3] Bits 8 to 11㧦Network Module 3 Station Type
(0㧦Not Equipped)
(5㧦Fieldbus Master Board)
[2] Network I/F Module 2 Station Type
(0㧦Not Mounted)
[1] Network I/F Module Station Type
0㧦Automatic Identification)
(5㧦Fieldbus Master Board)
431 Fieldbus Master
Function Select
0
H
0
H
to
FFFFFFFF
H
F
Bits 0-3 㧦 Function Select
(0㧦 Disable / 1㧦RC gateway)
Bits 4-7 㧦 Offline slave data Processing
Selection
(0㧦Clear /
1㧦Hold (most recent normal
retain)
432 Fieldbus slave
0 Composition definition
0
H
0
H
to
FFFFFFFF
H
F
Bits 0-7 㧦 Connection controller Station
Type
(0㧦Disconnected /
1㧦MSEP
2㧦ACON/PCON /
3㧦SCON-CA)
4㧦MSCON
Bits 8-15 㧦 Slave Input size (byte)
Bits 16-23 㧦 Slave Output size (byte)
433 Fieldbus slave
1 Composition definition
0
H
0
H
to
FFFFFFFF
H
F (I/O Parameter Equivalent to No.432)
434 Fieldbus slave
2 Composition definition
0
H
0
H
to
FFFFFFFF
H
F (I/O Parameter Equivalent to No.432)
435 Fieldbus slave
3 Composition definition
0
H
0
H
to
FFFFFFFF
H
F (I/O Parameter Equivalent to No.432)
436 Fieldbus slave
4 Composition definition
0
H
0
H
to
FFFFFFFF
H
F (I/O Parameter Equivalent to No.432)
437 Fieldbus slave
5 Composition definition
0
H
0
H
to
FFFFFFFF
H
F (I/O Parameter Equivalent to No.432)
438 Fieldbus slave
6 Composition definition
0
H
0
H
to
FFFFFFFF
H
F (I/O Parameter Equivalent to No.432)
439 Fieldbus slave
7 Composition definition
0
H
0
H
to
FFFFFFFF
H
F (I/O Parameter Equivalent to No.432)
440 Fieldbus slave
8 Composition definition
0
H
0
H
to
FFFFFFFF
H
F (I/O Parameter Equivalent to No.432)
