3. W
iring
34
Components required by the configuration shown in Example 2
Name Model Quantity
RS232 conversion unit RCB-CV-GW 1
Communication cable CB-RCB-SIO-ƑƑƑ 1
Power I/O Cable for SIO type CB-ERC2-PWBIO-ƑƑƑ 1
Network connection cable CB-ERC2-CTL001 1
Purchased
from IAI
Controller link cable CB-RCB-CTL002 2
Recommended cables 1, 2 HK-SB/20276 (Taiyo Cabletec Corporation) Lm Provided by
the customer e-CON connector
3-1473562-4 (AMP) 1
The above table only lists the components required for SIO communication. The customer must provide
other components that are required, such as a safety circuit, power supply and cables for their connection.
ƑƑƑ in the table indicates the cable length. Example: 050 = 5 m
