1.Outline of Control Method
18
[1] Monitor LEDs
NS MS
ScannerMode
The conditions of the slaves (each controller) and the network can be checked with the three LED
lamps, MS, NS and ScannerMode, mounted on the front face of RC Gateway Fieldbus Board.
LED Color
Indication
Status
Indication Description
Illuminating Online, connection of more than one line is established
Green
Flashing Online, no connection established
Illuminating Critical link error
Red
Flashing Connection timeout occurred in at least one node
NS
(Network Status)
- OFF
No power supply to DeviceNet
Not online
Illuminating Normal operation
Green
Flashing In automatic baud rate process
Illuminating Serious trouble
Red
Flashing Slight trouble
MS
(Module Status)
- OFF No power supply to DeviceNet
Green Illuminating In DeviceNet Master operation
Scanner Mode
- OFF No power supply to DeviceNet
[2] DIP switch
Not for use. (There should be no problem no matter what the setting of this switch is.)
