Micro-PWC CONFIGURATION GUIDE
System Configuration 45
Micro-PWC Operator Action messages are displayed in following format:
Operator action messages are classified into the following types:
• Network operator action
• Operator action
Operating messages can be filtered.
2.8.4.3.6 Message Class: Priority
To filter messages by Priority, click Priority Message Class on the Device Routing Assignment window
(
Figure 2-21 ). The Message Type area of the window will list all priorities. Click each priority for which rout-
ing is to be changed, or use Clear or Set to clear or set the routing status of all priorities.
2.8.4.3.7 Message Class: Area
To filter messages by Area, click Area Message Class on the Device Routing Assignment window
(
Figure 2-21 ). The Message Type area of the window will list all areas. Click each area for which routing is
to be changed, or use Clear or Set to clear or set the routing status of all areas.
2.8.5 Operator Window Parameters
The Operator Window Parameters menu item is used to access features which allow the user to:
• Choose update rates for Operator Windows containing graphic, group, point, or trend displays.
The rate can further be set separately for windows both with and without keyboard focus.
• Determine the maximum allowable memory size of Operator Windows; this is used to avoid
delays by triggering replacement of Operator Windows in memory.
• Determine the initial contents of an Operator Window when it is opened.
• Determine whether Operator Windows are arranged (tiled) automatically as they are opened
and closed, or arranged only on demand.
When this menu item is clicked on, the Operator Window Parameters window ( Figure 2-24 ) will be dis-
played.
