Micro-PWC CONFIGURATION GUIDE
Grafx Editor 169
Variables
Figure 4-45. Put Pushbutton Configuration Window, Part 2
button_label Enter the label to be displayed on the button (e.g., Start).
Default: None
face_color Enter the number of the desired face color of the button. (See any color pal-
ette in the Settings or Properties windows for color numbers.)
Default: 26 (used for FP_DYctrlpb)
low_color Enter the number of the desired lower edge color of the button.
Default: 29 (used for FP_DYctrlpb)
put_tagatom Enter the Tag.atom of the controller database point to which the data config-
ured in put_value will be written (e.g., MCV-R01A01.INB).
Default: None
put_tagatom2 Enter the Tag.atom of the controller database point to which the data config-
ured in put_value2 will be written.
Default: None
put_tagatom3 Enter the Tag.atom of the controller database point to which the data config-
ured in put_value3 will be written.
Default: None
