Micro-PWC CONFIGURATION GUIDE
22 System Configuration
2.6.1.3 Priority Colors
There are 16 alarm priorities available on the Micro-PWC. Each of these priorities can be configured to dis-
play in a different color, to aid in rapid identification of the importance of the alarm. A palette of 16 Priority
Color Assignments is pre-configured on the Micro-PWC. The default palette uses the following colors:
This color palette can be modified using the color palette and configuration utility in the Alarm Setup dis-
play.
To configure a color for a priority using pre-defined colors:
1. Click the Priority Color to be changed.
a. The name of the current color choice appears inside the selection entry box.
b. The current color is displayed in the color sample box located above the list box.
2. In the pre-defined list of colors, click the name of the color to be assigned to the selected
priority.
a. This color will replace the current color in the color sample box.
3. Click colors until a satisfactory color is found.
4. Click Assign Color to assign the newly chosen color to the selected priority
Table 2-1. Priority Color Assignments
Level Color Rank
Priority 1 Red (Highest priority)
Priority 2 Yellow
Priority 3 Green
Priority 4 SlateBlue
Priority 5 HotPink
Priority 6 Cyan
Priority 7 DarkOrange
Priority 8 Blue
Priority 9 Aquamarine
Priority 10 SeaGreen
Priority 11 Chocolate
Priority 12 Lavender
Priority 13 SandyBrown
Priority 14 Tomato
Priority 15 Turquoise4
Priority 16 DeepPink (Lowest priority)
