Micro-PWC CONFIGURATION GUIDE
Grafx Editor 209
4.5 Micro-PWC Symbols
Micro-PWC Symbols are standard, static submodels, pre-configured and supplied by MicroMod. Symbols
are objects which represent standard items such as vessels, tanks and storage bins. Symbols which corre-
spond to those defined by the Instrument Society of America (ISA) have the prefix ISA_. Non-ISA symbols
created by MicroMod contain the prefix FP_ST. (Dynamic attributes can be assigned to these submodels
via the Dynamic Attributes menu item.)
The following sections contain tables which list the available ISA and Micro-PWC Symbols by category.
Each table lists the name of the symbol, followed by a brief description.
Table 4-7. Valves and Actuators
SYMBOL NAME DESCRIPTION ILLUSTRATION
FP_STvlv3 3 Way Valve Body Figure 4-88 , Item A
FP_STvlv3actr 3 Way Valve with On-Off Actuator Figure 4-88 , Item B
FP_STvlv3matr 3 Way Valve with Manual Actuator Figure 4-88 , Item C
FP_STvlv3tact 3 Way valve with throttling Actuator Figure 4-88 , Item D
ISA_ACTR On-Off Actuator Figure 4-89 , Item A
ISA_BVLV Butterfly Valve Figure 4-89 , Item H
ISA_CVLV Check Valve Figure 4-89 , Item F
ISA_MATR Manual Actuator Figure 4-89 , Item B
ISA_RVLV Relief Valve Figure 4-89 Item E
ISA_TACT Throttling Actuator Figure 4-89 , Item C
ISA_VLV3 3 Way Valve Body Figure 4-89 , Item G
ISA_VLV3_ACTR 3 Way Valve with On-Off Actuator Figure 4-89 , Item M
ISA_VLV3_MATR 3 Way Valve with Manual Actuator Figure 4-89 , Item L
ISA_VLVE Valve Body Figure 4-89 , Item D
ISA_VLVE_ACTR Valve with On-Off Actuator Figure 4-89 , Item I
ISA_VLVE_MATR Valve with Manual Actuator Figure 4-89 , Item K
ISA_VLVE_TACT Valve with Throttling Actuator Figure 4-89 , Item J
