Micro-PWC CONFIGURATION GUIDE
212 Grafx Editor
Table 4-14. Filters
SYMBOL NAME DESCRIPTION ILLUSTRATION
ISA_LFLT Liquid Filter Figure 4-94 , Item A
ISA_VFLT Vacuum Filter Figure 4-94 , Item D
Table 4-15. Scrubbers and Precipitators
SYMBOL NAME DESCRIPTION ILLUSTRATION
ISA_EPCP Electrostatic Precipitator Figure 4-94 , Item B
ISA_SCBR Scrubber Figure 4-94 , Item C
Table 4-16. Separators
SYMBOL NAME DESCRIPTION ILLUSTRATION
ISA_CSEP Cyclone Separator Figure 4-94 , Item E
ISA_RSEP Rotary Separator Figure 4-94 , Item F
ISA_SDRY Spray Dryer Figure 4-94 , Item G
Table 4-17. Heat Transfer Devices
SYMBOL NAME DESCRIPTION ILLUSTRATION
ISA_FAXR Forced Air Exchanger Figure 4-95 , Item D
ISA_FURN Furnace Figure 4-95 , Item C
ISA_KILN Rotary Kiln Figure 4-95 , Item E
ISA_XCHG1 Exchanger Figure 4-95 , Item A
ISA_XCHG2 Exchanger Figure 4-95 , Item B
