Micro-PWC CONFIGURATION GUIDE
Grafx Editor 203
Variables
on_tagatom Enter the tagname.atom of a controller database point (i.e., DCD_0.OUT1);
the value of this point will be used by the variable on_value (described below)
to initiate the "spin" dynamic and change the fill color in the submodel.
(User must define variable.)
on_value The value entered here will be compared with the value of the controller
database point configured in the variable on_tagatom. When the value of the
tagname.atom matches the value configured here for on_value, the color of
the pump will change to that defined in the variable pump_on_color and the
wheel portion of the submodel will appear to spin.
(User must define variable.)
period Enter the frequency at which the wheel spokes will appear to change position.
The period is measured in tenths of a second; the number entered here
defines how many tenths of a second are in the period (e.g., a "5" entered
here means the period would be 0.5 seconds in duration).
Default: 1 (One tenth of a second.)
pump_off_color Enter the number of the fill color to be used for the pump submodel when the
controller database point configured in the variable on_tagatom is not equal to
the value configured in the variable on_value.
Default: 0 (Black)
pump_on_color Enter the index number of the fill color to be used for the pump submodel
when the controller database point configured in the variable on_tagatom is
equal to the value configured in on_value.
Default: 0 (Black)
spoke_color Enter the index number of the color to be used for the spokes of the wheel
portion of the submodel.
Default: 0 (Black)
wheel_color Enter the index number of the color to be used for the interior of the wheel por-
tion of the submodel.
Default: 0 (Black)
