Micro-PWC CONFIGURATION GUIDE
154 Grafx Editor
Variables
TagAtom Enter the Tag.atom of the controller database point (or a constant value) that
is used to determine the length of the bar (e.g., tcPID.pv).
(User must define variable.)
bar_color Enter the number of the desired fill color of the bar. (See any color palette in
the Settings or Properties windows for color numbers.)
Default: 7 (White)
axis_color Enter the number of the desired color of the y-axis.
Default: 0 (Black)
direction Enter the number from the table below representing the direction that the bar
fills as the value of Tag.atom increases from lower_limit to upper_limit.
DIRECTION DIRECTION VALUE
up 1
down 0
Default: 1
label_color Enter the number of the desired color of the y-axis labels.
Default: 0 (Black)
lower_limit Enter the Tag.atom of the controller database point or the constant value that
represents the lower limit of the bar (e.g., 0).
Default: None
(User must define variable.)
upper_limit Enter the Tag.atom of the controller database point or the constant value that
represents the upper limit of the bar (e.g., 100).
Default: None
(User must define variable.)
y_ticks Enter the number of tick marks to be displayed on the y axis.
Default: 0
