Micro-PWC CONFIGURATION GUIDE
20 System Configuration
2.6 Configuring Network Parameters
To configure parameters which are global to the network, use the Network Parameters option. From the
System Window, select Menu > Configure > Network Parameters. This provides configuration access to
the following network parameters:
• Alarm Setup
• Alarm Vectors
• Area Names
• Event Bit Names
• Printer Assignment
• Message Routing
• Operator Window Parameters
• Display Colors
2.6.1 Alarm Setup
The parameters configured via Alarm Setup affect the System Title and the display of Alarm information,
both of which appear in the Mini-Alarm Window.
Select Menu > Configure > Network Parameters > Alarm Setup to configure the following parameters:
• System Title (appears in title bar of the Mini-Alarm Window)
• Alarm presentation on top line of Mini-Alarm Window (with all alarms acknowledged)
• Alarm presentation on top line of Mini-Alarm Window (with unacknowledged alarms)
• Audible Alarm configuration
• Priority color assignments
• Mini-Alarm Window field widths
Selecting the Alarm Setup option displays the Alarm Setup window ( Figure 2-9 ).
• The main work area of the Alarm Setup window is divided into several smaller areas, including
the System Title entry box, Top Alarm Line Presentation configuration, Audible Alarm
configuration, and a utility for configuring and assigning custom Priority Colors.
