Micro-PWC CONFIGURATION GUIDE

216 Grafx Editor

Figure 4-92. ISA Standard Symbols - Mixing and Material Handling Equipment

TP81066A

A. ISA_CNVR

D. ISA_MILL

E. ISA_AGIT

F. ISA_AGIT_MOTR

B. ISA_RFDR

C. ISA_RSTD

G. ISA_IMIX

H. ISA_SCNV
