Micro-PWC CONFIGURATION GUIDE
Grafx Editor 165
Variables
TagAtom
Enter the Tag.atom of the controller database point to which the data will be
written (e.g., tcPID.sp).
(User must define variable.)
button_label
Enter the label to be displayed on the button (e.g., SP).
Default: None
face_color
Enter the number of the desired face color of the button. (See any color
palette in the Settings or Properties windows for color numbers.)
Default: 26
low_color
Enter the number of the desired lower edge color of the button.
Default: 29
txt_color
Enter the number of the desired text color of the button label.
Default: 4
up_color
Enter the number of the desired upper edge color of the button label (e.g., 23
used for FP_DYctrlpb).
Default: 23
