Chapter 31 Diagnostics
X6004 User’s Guide
447
Filename This field displays the name of the packet capture data file.
File naming convention is channel_line/port_diag_date.tgz, where:
• channel - This is based on the selected Channel Type. For
example, if you choose ‘SIP’ in the channel type menu then the file
name begins with the word sip.
• line/port - This indicates the line or port that was sniffed.
• diag - This word is non-variable and indicates the file is diagnostic.
• date - The date is expressed as a 14-digit string:
yyyymmddhhmiss, where yyyy is the year (‘2009’), mm is the
month (‘05’), dd is the day (‘15’), hh is the hour (1-24), mi is the
minute (1-60) and ss is the seconds (1-60). In this example, the
string 20090515 equates to the year 2009, the month of May, and
the 15th day.
• tgz - This is the Unix TAR filetype.
Last Modified This field displays the date and time when the information was collected
from the X6004.
Size This field displays the size of the file.
Download Click Download to save the file to your computer.
Table 174 Diagnostics > Voice Sniffer (continued)
LABEL DESCRIPTION
