Chapter 10 Phonebook
X6004 User’s Guide
200
10.4 The Local Phonebook Screen
Use this screen to set up the local phonebook settings on the X6004. To access
this screen, click Configuration > PBX > Server Configuration > Phonebook.
Figure 85 Phonebook > Local Phonebook
Each field is described in the following table.
Default Click Default to set every field in this screen to the factory defaults
configured on the X6004.
Note: This not only sets the fields to default values but also
automatically saves the default mappings to the X6004.
Name..
Department This table displays the phonebook entries retrieved from the LDAP
database.
Regular update
at Select this and specify the time in hour and minute format at which the
X6004 should update the LDAP phonebook with the LDAP database.
Click Set to save this setting.
Refresh Click Refresh to immediately update the LDAP phonebook with the LDAP
database.
Table 45 Phonebook > LDAP Phonebook (continued)
LABEL DESCRIPTION
Table 46 Phonebook > Local Phonebook
LABEL DESCRIPTION
Local
Phonebook This screen allows you to view, edit and remove local phonebook
entries on the X6004.
Delete Select the Delete checkbox and click Delete to remove a local
phonebook entry from the X6004.
Name This field displays the Name field value of the local phonebook entry.
Ext. This field displays the Ext. field value of the local phonebook entry.
Home This field displays the Home field value of the local phonebook entry.
Mobile This field displays the Mobile field value of the local phonebook entry.
E-mail This field displays the E-mail field value of the local phonebook entry.
Logon Name This field displays the Logon Name field value of the local phonebook
entry.
