Chapter 28 Call Detail Record (CDR)
X6004 User’s Guide
421
28.3 The Backup Screen
Use this screen to backup CDR files, delete existing backups of CDR files and mail
CDR files to an administrator email address.
Figure 243 CDR > Backup List
Each field is described in the following table.
Table 161 CDR > Backup List
LABEL
DESCRIPTION
Backup File List If you have a ZyStack configured using multiple X6004s, then specify
the X6004 for which you want to create a backup file of the CDRs.
Filename
This column displays the names of the backup CDR files currently
stored on the X6004. Use the check box on the left to specify which files
you want to forward or delete. The filename of the CDR takes the
following format: “cdr.YYYYMMDDHHMMSS.tgz”
Where:
• cdr - indicates this is a Call Detail Record file.
• YYYYMMDD - is the year, month, and day indicating when the
backup file was created.
• HHMMSS - is the time of the day indicating when the backup file
was created in hour, minute, second format.
• tgz - indicates that this is a compressed. That can be decompressed
using a compression utility such as WinRAR. The resulting
decompressed files are MySQL database files that can be managed
via a MySQL DBMS (Database Management System). See
Database Management via MySQL on page 418
Note: The X6004 can store only three CDR backup files at a time. If
you create a new backup file when you already have three
files created, then the oldest backup file is deleted from the
system.
Forward
Check the boxes next to the files you want to forward to the
administrator email address and click the Forward button. The files
you forward to an administrator are deleted from the X6004.
Delete
If you no longer want to store a CDR file on the X6004 then check the
boxes next to the files you want to delete from the X6004 and click the
Delete button.
Backup Now
Click the Backup Now button to save a CDR backup file on the X6004.
